ELKAY OUTDOOR TOUCH TIMER MANUAL

If no one is present in the room or the detection zone is not passed through, during its set time period the timer will time out, turning off the lights or appliance and the blue indicator/locator ring will light up.

The unit will then wait 20 seconds approximately before allowing the PIR unit to sense and re-trigger the timing period again. Each time the PIR is triggered the red LED will light and reset the timer back to the start of the timing period.

In standard operation, the PIR will now sense body heat when passing through the detection zone.

Connections must be done up tightly with a spanner Rubber washers can deform when used with metal glands. As a general rule, nylon washers work best with this type of application.

You will still need a nylon sealing washer to maintain the IP rating from the gland to the switch housing back box. The IP rating for the SWA gland guarantees only the connections to the SWA cable. SWA Glands – SWA glands can be used but must be IP rated. Ensure sealing washers are used with all connections and all glands and connections are done up tightly with a spanner to ensure water tightness. Clip on front fascia plate.įlexible Cable – It is always better to use cable glands with flexible cable, with the gland connected at the bottom, rather than through the top. Mount timer unit onto surface mount box using the four screws at all four corners ensuring even connection with the seal-Place screw cover seals It is essential that the correct IP 66 rated connections are made to keep the integrity of the IP rated back box maintained. Place screw cover seals over the mounting screws. Mount the surface mount box on a secure surface using the mounting pack supplied. If required and to ensure IP66 waterproof rating, please use a suitable M20 cable gland use appropriate sealing washers. It is recommend the hole is cut with a 20mm hole saw for cleanest effect. Take the surface mount box and remove the knock out section. Outdoor Unit can only be used in conjunction with the surface mount box supplied. Ensure that there is adequate space for wiring. Please ensure that the top and bottom lugs are removed, if ﬁ tted, from metal wall boxes prior to ﬁtting. Your Elkay unit is compatible with a single gang, 25mm deep, British Standard accessory plate. Turn off the mains supply for installation. Please note that it is essential that the Live In wire and switch Live Out is identiﬁ ed prior to commencing installation. Do not site the unit on a vibrating surface, or near a forced-air heating or ventilation (see diagram 2). Ensure that the sensor is not adjacent to the load. When locating the position of the unit avoid subjecting the sensor to direct sunlight.

Use the detection range to determine a suitable location for the sensor.

ELKAY OUTDOOR TOUCH TIMER MANUAL

In dark conditions the manual override disables the PIR allowing the lights to be turned off indeﬁ nitely or when the override switch is re-pressed. This allows the lights to be turned on for the set period of time when the ambient light level is such that the lights would not usually come on. The unit has a lux level adjustment, which measures the ambient light levels and prevents lighting from being switched on when there is sufficient light in the room.Your Elkay PIR timer has the added beneﬁ t of a manual override facility. If moving body heat is detected again during the timing period, the timing sequence will restart. When body heat is no longer detected, the unit will switch off after the adjustable time period has elapsed. The unit is switched on by the detection of moving body heat within a speciﬁ ed range.

Hands-free filling with automatic timed shut off to help prevent accidental spillsĪmbient Water (Chiller available separately)The outdoor PIR timer has been designed to control lighting, heating, and ventilation.

Optional setting prevents unsupervised use.

Lights indicator when quick and easy filter changes are needed.

Glass-front and brushed stainless steel design looks great in any room interactive lighting brightens when dispensing water.

Backlit LED Green Ticker counts the number of disposable, single-use plastic bottles saved.

Fits within the width and depth of two wall studs near water and electric includes drip tray with optional drain connection.

*Preorder item available in two colour finishings Ideal for contemporary office, homes, conference rooms, lobbies and commercial locations. Featuring interactive lighting and Green Ticker™ counting the number of plastic bottles saved with each refill. Contemporary design in-wall water dispenser with sensor activated hands-free bottle filling.
